HinkleyModel 48310
Bray Swing Arm Single Light Sconce by Hinkley
Bray Swing Arm Single Light Sconce by Hinkley
- 465 mm from the wall
- Damp rated
- E27, dimmable
- Converted to 230 V for NZ
In stock, dispatched within 5 to 10 working days
Free delivery to most NZ addresses. Delivery details
Couldn't load pickup availability
- Authorised Hinkley stockist
- Converted to 230 V for NZ, SDoC on request
- NZ family business, delivering nationwide
Bray Swing Arm Single Light Sconce by HinkleyLacquered Brass
$672Price match promise
Size and placement
Get the height right
Typical mounting heights. Your electrician will confirm the final position.
-
Bedside
Centre the backplate about 1.2 to 1.5 m from the floor, so the shade sits just above your head when sitting up.
-
Reading chair
Mount to the side of the chair, roughly level with the top of the chair back plus 300 to 400 mm.
-
Reach
The shade sits 465 mm out from the wall, so allow the same clearance from doors and walkways.
Specifications
| Width | 140 mm |
|---|---|
| Height | 427 mm |
| Projection from wall | 465 mm |
| Backplate | 140 × 171 mm |
| Top of fitting to wall box | 343 mm |
| Weight | 2.0 kg |
| Lamp | 1 × E27, LED up to 10 W |
| Dimming | Dimmable with a dimmable lamp and compatible dimmer |
| Location | Indoor, including bathrooms (US damp rated) |
| Electrical | Converted to 230 V for NZ. Supplier Declaration of Conformity available on request |
| Model numbers | 48310LCB, 48310LCB-CI |
Overview
Size:
140mm Wide x 427mm High x 465mm Deep
Light:
1x max 10W Medium Base E27 LED Lamp
Finish:
Lacquered Brass Finish
or Lacquered Brass Finish w/ Chalk White accents
Perfectly styled and fantastically functional, Bray’s simple design features a clean, swivelling conical shade held by a slim articulating arm.
Downloads
These are the supplier's US documents. Your light is converted to 230 V for New Zealand.
Delivery and installation
In-stock showroom items are usually dispatched the next working day. Warehouse items are dispatched within 5 to 10 working days. Delivery is free on orders over $499 to most New Zealand addresses; oversized items are charged at our oversized rate. Shipping policy
Hardwired lights must be installed by a licensed electrician.
Good to know
Questions customers ask
Quick answers before you buy.
Which bulb does it take?
One E27 bulb. Use an LED of up to 10 W.
Can it go in a bathroom?
Yes. It's US damp rated, which suits bathrooms outside the wet zones. Your electrician will confirm placement against the NZ zones.
Is it dimmable?
Yes, with a dimmable bulb and a compatible dimmer switch. Your electrician can confirm the dimmer.
Is it suitable for New Zealand?
Yes. It is converted to 230 V for New Zealand, and a Supplier Declaration of Conformity is available on request.
Will you match a lower price?
Yes. If another authorised New Zealand retailer advertises the same product, in the same finish, for less, send us the link before you order and we will match it. The details are on our price match promise page.
